Great Dane 8 x 8
Vehicle Details
The Great Dane 6 x 6 is a highly capable and customizable vehicle produced in variants of 4, 6, 8 or 10 wheels. All vehicles in the system use the same serviceable components - a true “Vehicle System”, enabling the Great Dane's configuration to be adapted in about 2 hours using different mission kits. Powered by a 600 HP Caterpillar engine with 6 speed transmission, in a fully protected engine assembly, the Great Dane has a great amount of power available. The Great Dane also features driver selectable all wheel steering, high wheel travel, joystick operated active suspension as well as lowering suspensions for quick troop ingress/egress. The vehicle features a modular armor system, which allows for changing survivability protection levels higher, lower or as required. The Great Dane can seat between 10 and 14 personnel in the vehicle, with 4 crew in the front cockpit. It also has the ability to mount 1 man, 2 man or Remote Weapon Systems, Up Gunned Weapon Stations, or LAV type turrets with 25, 30 or 40mm interchangeable main weapons.
1. DIMENSIONS | |
Overall Length, mm | 9710 |
Overall Width, mm | 2620 |
Overall Height, mm | 2640 |
Wheelbase, mm | 2110/1760/1760 |
Track Width, mm | 2184 |
Ground Clearance, mm | 320-700 (adjjustable) |
2. VEHICLE LAYOUT | |
Body layout | Monocoque |
Seating layout | 4+8 (Optional 4+10) |
Doors | 1 (rear ramp) + hatches |
Roof turret with hatch | Yes |
3. WEIGHTS | |
Curb weight, kg | 29030 |
Payload, kg | 2400 |
Combat weight, kg | 31430 |
4. POWERTRAIN | |
Engine make | Caterpillar |
Engine model | C13 |
Engine type | Turbo charged diesel I6 |
Displacement, l | 12.5 |
Maximum Power, hp | 600 |
Maximum Torque, Nm | 2373 |
Fuel type | diesel |
Power to Weight Ratio at combat weight, hp/ton | 19.1 |
Transmission | automatic 6-speed |
Fuel Tank Capacity, l | 530 |
5. RUNNING GEAR | |
Driveline | 8x8x8 (all wheels steering) |
Axle and suspension FR | Independent hydropneumatic with adjustable ride height |
Axle and suspension RR | |
Transfer case | 2 speed |
Run flat inserts | Yes |
CTIS / STIS | CTIS |
Brakes FR | Heavy-Duty Inboard Pneumatic Disc Brakes |
Brakes RR | Heavy-Duty Inboard Pneumatic Disc Brakes |
6. MOBILITY | |
Top Speed, km/h | 113 |
Turning Circle, m | 18.88 |
Grade ability | >60% |
Static Side Slope | Up to 50% |
Vertical Step, mm | 700 |
Fording, mm | 2000 (90° edges) |
8. ELECTRICAL SYSTEM | |
Voltage | Dual 12V and 24V |
Batteries | 2 |
Alternator | 570A |
Auxiliary sockets 12V | Yes |
120 / 220V AC external power input | Optional |
NATO slave starting system | Yes |
Battery monitor | Yes |
7. PROTECTION | |
Ballistic protection | ? |
Mine Protection | ? |
Ballistic Protection | Very high protection level; details on application |
Mine Protection | Details on application |
1) Electric winch | Standard, 30000 lbs |
2) CBRN overpressure system | Standard |
3) Public address system | Standard |
4) Intercom | Optional |
5) Fire suppression system | Standard, 4 zone |
6) Auxiliary service battery with smart isolator switch and battery monitor | Standard |
7) Interior weapon mounts | Optional |
8) VHF/UHF communication system | Optional |
9) MF/HF communication system | Optional |
10) GPS | Optional |
11) DVR | Optional |
12) GSM based live video monitoring system | Optional |
13) Smoke grenade launchers | Optional |
14) Multiple launch system for smoke grenades | Optional |
15) Remote controlled weapon station | Optional |
16) Gunshot detection system | Optional |
17) Remote controlled search lights | Optional |
18) Forward looking thermal camera | Optional |
19) Reverse day/night camera | Standard |
20) Perimeter day/night cameras | Optional |
21) Outboard telescopic mast (pneumatically or electrically operated) | Optional |
22) IR driving and convoy lights | Optional |
