DIMENSIONS
Overall Length : 5226 mm (without spare wheel)
Overall Width : 1874 mm over body
Overall Height : 2180 mm over the roof plate
Wheelbase : 3180 mm
Track Width : 1589 mm
Ground Clearance : 290 mm under differentials
Angle of Approach : 41°
Angle of Departure : 33°
VEHICLE LAYOUT
Seating layout : 2+6 (optional 2+8 with bench seating)
Doors : 3
Roof turret with hatch : Optional
WEIGHT
Curb weight : 4600 kg (standard protection)
Payload : 1000 kg
Combat weight : 5600 kg
POWERTRAIN
Engine make : Toyota
Engine model : 1VD-FTV
Engine type : Liquid cooled, direct injection, four stroke, turbo charged, Inter cooled, 8 cylinders in V-shape, 32 valves, diesel
Displacement : 4461 cm3
Maximum Power : 195 hp @ 3300 rpm
Maximum Torque : 430 Nm @ 1200 to 3200 rpm
Fuel type : Diesel
Power to Weight Ratio : 35.45 hp/ton @ combat weight
Transmission : 5-speed manual
Fuel Tank Capacity : 2 x 90L
RUNNING GEAR
Driveline : Selectable 4×4
Steering : Recirculating ball, hydraulically assisted
Suspension : Front – coil springs with hydraulic shock absorbers
Rear – leaf springs with hydraulic shock absorbers
Rims : 9.00 x 17” steel wheels rated to 1550 kg each
Tires : Hankook Dynapro 37 x 12.5 R17 rated to 1650 kg
Run flat inserts : Fitted as standard
STIS : Optional
Brakes : Front – ventilated 4 piston heavy duty disc brakes
Rear – 4 piston disc brakes
MOBILITY
Top Speed : 100 km/h
Turning Circle : 14.4 m (curb to curb)
Fuel Range : 800 km
Grade ability : 60%
Static Side Slope : 30%
Vertical Step : 350 mm
Trench Crossing : 750 mm
Fording : 700 mm (Unprepared)
ENVIRONMENTAL CONDITIONS
The vehicle can be operated effectively in ambient temperatures ranging from – 20°C to + 55 °C
PROTECTION
Ballistic protection : The crew compartment all round protection against Kinetic Energy weapons conforms to STANAG 4569 Level I.
Mine Protection : STANAG 4569 Level I
OPTIONAL EQUIPMENT (Please consult Sales Department for possible combinations)
